Características
Está es una bicicleta de carretera ideal para los ciclistas más fuertes, la hemos realizado pensando en un tipo de complexión fuerte y corpulenta.
Diagrama
Medidas
| Talla | 470 | 500 | 530 | 560 | 590 | ||
| A | STACK | mm | 516 | 522,7 | 539,6 | 552,1 | 575,3 |
| B | REACH | mm | 375,3 | 381,2 | 385,6 | 391,8 | 399,5 |
| C | HEAD TUBE LENGTH | mm | 110 | 120 | 130 | 140 | 150 |
| D | HEAD TUBE ANGLE | o | 71,5 | 72 | 72,5 | 73 | 73,5 |
| E | BB DROP | mm | 72 | 72 | 72 | 72 | 72 |
| F | FORK LENGTH FULL | mm | 373 | 373 | 373 | 373 | 373 |
| G | FORK RARE/OFFSET | mm | 43 | 43 | 43 | 43 | 43 |
| H | FRONT CENTER | mm | 574,6 | 577,5 | 583 | 589,8 | 596 |
| I | CHAINSTAY LENGTH | mm | 406 | 406 | 406 | 406 | 406 |
| J | TOP TUBE LENGTH HORIZONTAL | mm | 515 | 530 | 545 | 565 | 585 |
| K | SEAT TUBE LENGTH | mm | 440 | 470 | 500 | 530 | 560 |
| L | SEAT TUBE ANGLE | o | 74,5 | 74 | 73 | 73,5 | 73 |
| M | WHEELBASE | mm | - | - | - | - | - |
Especificaciones
| Material | T800 | |||
| Head tube | 1 1/2" -1/ 1/2" | |||
| CABLE ROUTING | Internal | |||
| BOTTOM BRACKET | Pressfit BB86.05 | |||
| MAX TIRE | 30 | |||
| BRAKE | Disc Brake | Flat Mount | 140/160 mm | |
| MAX CHAINRING | 55-42T | |||
| SEAT POST | Specific 350mm lenght*15 mm | |||
| O.L.D. | FORK | 12*100 mm | REAR | 12*142 mm |
| CABLE PLUG | Mechanical and Digital |
Pesos
| FRAME | 1090 gr |
| FORK | 440 gr |
| SEAT POST | 200 gr |
| HANDLEBAR | 360 gr |
Comprueba nuestra disponibilidad en tiendaVer modelos ALPE D' HUEZ
